Brief Description: 9mm Box fuse, quick low breaking ability
9mm Box fuse, quick low breaking ability
Package: Radial Lead Squared Fuse
Radial Lead Squared Fuse
Time - current features: Time-Lag (T)
Time-Lag (T)
Dimension (mm): 12,3x9,60x6,4 mm (head)
12,3x9,60x6,4 mm (head)
Rated voltage: AC:250V/300V
AC:250V/300V
Breaking capacity: 300A@125V/250V/300V/400V AC
300A@125V/250V/300V/400V AC
Certification: CQC, TUV, cURUS
CQC, TUV, cURUS
Operating temperature: -55°C ~ +125°C
-55°C ~ +125°C
Soldering Parameters: 260°C≤5 seconds(wave-soldering), 350°C≤3 seconds(hand welding)
260°C≤5 seconds(wave-soldering), 350°C≤3 seconds(hand welding)
Soldering Peak: 260°C, 10 seconds, /280°C, 5 seconds
260°C, 10 seconds, /280°C, 5 seconds
Storage Conditions/Humidity: +10°C ~ +60°C. Average annual relative humidity ≤75%,dry maximum value of 30 days is 95%
+10°C ~ +60°C. Average annual relative humidity ≤75%,dry maximum value of 30 days is 95%
Enviroments: Reach, RoHS compliant
Reach, RoHS compliant
Cross Ref. Manufacturers:
Littlefuse, Eaton, Bourns, Vishay, Schurter
