Brief Description: TVS over-voltage protection, smd mounting plastic package, with Glass passivated or planar junction, Low profile package and low inductance, Excellent clamping capability.
TVS over-voltage protection, smd mounting plastic package, with Glass passivated or planar junction, Low profile package and low inductance, Excellent clamping capability.
Package: DO-214AA package
DO-214AA package
Standard: MSL level 1, per J-STD-020.
MSL level 1, per J-STD-020.
Operating temperature: see spec
see spec
Storage Conditions/Humidity: see spec
see spec
Enviroments: Reach, RoHS compliant
Reach, RoHS compliant
Repetition rate(duty cycle): 0.01%
0.01%
Peak Pulse power capability at 10×1000μs waveform: 600W
600W
Typical IR: Less than 1μA above 10V
Less than 1μA above 10V
Fast response time: typically less than 1.0ps from 0V to VBR min.
typically less than 1.0ps from 0V to VBR min.
High temperature soldering: 260°C/10s at terminals
260°C/10s at terminals
Cross Ref. Manufacturers:
Littlefuse, Bourns, Vishay,Wurth, TDK
