Brief Description: 5mm Tube Fuse, Miniature Cartridge Fuse
5mm Tube Fuse, Miniature Cartridge Fuse
Time - current features: Fast-Acting (F)
Fast-Acting (F)
Rated current: 500mA - 10A
500mA - 10A
Breaking capacity: 10kA@125VAC，1.5kA@125VAC
10kA@125VAC，1.5kA@125VAC
Certification: KC、PSE、cURus、VDE、CQC、CCC、TUV
KC、PSE、cURus、VDE、CQC、CCC、TUV
Operating temperature: -55°C ~ +125°C
-55°C ~ +125°C
Soldering Parameters: 260°C.≤5 sec (Wave Soldering)，350°C.≤3 sec (Hand Soldering)
260°C.≤5 sec (Wave Soldering)，350°C.≤3 sec (Hand Soldering)
Soldering Peak: 260°C, 10sec., 280°C, 5sec.
260°C, 10sec., 280°C, 5sec.
Storage Conditions/Humidity: +10°C—+60°C, relative humidity ≤75% yearly average, without dew, maximum 30 days at 95%
+10°C—+60°C, relative humidity ≤75% yearly average, without dew, maximum 30 days at 95%
Cross Ref. Manufacturers:
Littlefuse, Eaton, Bourns, Vishay, Schurter
