Brief Description: 9mm Box Fuse, quick low breaking ability
9mm Box Fuse, quick low breaking ability
Package: Radial Lead Squared Fuse
Radial Lead Squared Fuse
Time - current features: Fast-Acting(F)
Fast-Acting(F)
Dimension (mm): 8,3x7,60x4,1 mm (head)
8,3x7,60x4,1 mm (head)
Rated voltage: AC: 400V, DC: 250V
AC: 400V, DC: 250V
Breaking capacity: 130A@250Vac
130A@250Vac
Operating temperature: -55°C ~ +125°C
-55°C ~ +125°C
Soldering Parameters: 260°C≤5 seconds(wave-soldering), 350°C≤3 seconds(hand welding)
260°C≤5 seconds(wave-soldering), 350°C≤3 seconds(hand welding)
Soldering Peak: 260°C, 10 seconds, /280°C, 5 seconds
260°C, 10 seconds, /280°C, 5 seconds
Storage Conditions/Humidity: +10°C ~ +60°C. Average annual relative humidity ≤75%,dry maximum value of 30 days is 95%
+10°C ~ +60°C. Average annual relative humidity ≤75%,dry maximum value of 30 days is 95%
Enviroments: Reach, RoHS compliant
Reach, RoHS compliant
Cross Ref. Manufacturers:
Littlefuse, Eaton, Bourns, Vishay, Schurter
